Máy gấp, dán băng keo tự động, Semi automatic flaps folding carton sealer GPC-50

Danh mục:

Mô tả

Semi automatic flaps folding carton sealer GPC-50

Specification

1 Imported parts, electrical and pneumatic components

2 Manually adjust the height and the width for different size of cartons;

3 Advanced pneumatic control system compare with the complicated electrical control system

4 Fold the top covers automatically, side belts driven top and bottom sealing

5 Cutter Safety system to prevent hands form stabbed by the cutter

6 Both steel and stainless steel types

Technical parameter

Model GPC-50
Conveyor speed 20m/min
Max. Packing size L600×W500×H500mm
Min. Packing size L200×W150×H150mm
Power supply 110V, 220-240V, 50/60Hz, 1Phase
Power 400W
Adhesive tape width 48mm, 60mm, 75mm
Machine dimension L1770×W850×H1520mm
Machine weight 250kg

Parts adopted

1.Motor : Taiwan GPG
2.Power switch: Korea KACON
3.Bearing : Japan NSK
4.Cutter :Japan SKD11
5.Conveyor Belts: import from Italy
6.Caster :YX-200
7.Touched Switch: Japan OMRON
8.Intermediate Relay : Japan IDEC
9.AC Contactor :France Schneider
10.Cylinda   : Taiwan SHAKO

11. Magnetic valve: Taiwan SHAKO
