Máy dựng thùng carton tốc độ cao, Automatic carton erector GPK-40, GPK-40H18

Danh mục:

Mô tả

Automatic carton erector  GPK-40



Specification:

1 Vertical storage, cartons can be added at any time without stopping the machine;

2 Suitable for forming and sealing cartons of the same size.

3Manually adjust to change the carton sizes(finishing in 2-3minutes);

4Advanced photoelectricity induction control system

5Rationally designed, the forming, folding and sealing process are accomplished simultaneously;

6 Cutter Safety system to prevent hands form stabbed by the cutter

7 Heavy duty built, both steel and stainless steel types

Technical parameter

Model GPK-40
Forming and sealing speed 12ctns/min
Carton storage quantity 100pcs (1000mm)
Carton size L250-450×W150-400×H100-400mm
Power supply 110/220V, 50/60Hz, 1 Phase
Power 200W
Applicable tape 48/60/75mm (Choose one type)
Machine size L2000×W1900×H1450mm
Machine weight 450kg

Parts adopted

1.Motor : Taiwan GPG
2.Power switch: Korea KACON
3.Bearing : Japan NSK
4.Cutter :Japan SKD11
5.Conveyor Belts: import from Italy
6.Caster :YX-200
7.Sensor:German LEUZE
8.Intermediate Relay : Japan IDEC
9.AC Contactor :SCHNEIDER
10.Cylinda   : Taiwan SHAKO
11.Magnetic Valve: Taiwan SHAKO
12.PLC :Germany Siemens
13.Touch Panel: MCGS



Automatic carton erector GPK-40H18

Specification:

1 Vertical storage, cartons can be added at any time without stopping the machine;

2 Suitable for forming and sealing cartons of the same size.

3Manually adjust to change the carton sizes(finishing in 2-3minutes);

4Advanced photoelectricity induction control system

5Rationally designed, the forming, folding and sealing process are accomplished simultaneously;

6 Cutter Safety system to prevent hands form stabbed by the cutter

7 Heavy duty built, both steel and stainless steel types

Technical parameter

Model GPK-40H18
Power supply 110/220V, 50/60Hz, 1 Phase, 200W
Packing speed 18ctns/min
Carton size L200-400×W180-350×H100-350mm
Tape width 48mm, 60mm, 75mm (Choose one type)
Air compressing 6kg/cm³
Air consumption 450NL/min
Machine size L2400×W2050×H1450mm
Machine weight 550kg

Parts adopted

1.Motor : Taiwan GPG
2.Power switch: Korea KACON
3.Bearing : Japan NSK
4.Cutter :Japan SKD11
5.Conveyor Belts: import from Italy
6.Caster :YX-200
7.Sensor:German LEUZE
8.Intermediate Relay : Japan IDEC
9.AC Contactor :SCHNEIDER
10.Cylinda   : Taiwan SHARKO
11.Magnetic Valve: Taiwan SHARKO
12.PLC : Germany Siemens
13.Touch Panel: MCGS
